SMALL IN SIZE, HUGE IN PRESENCE

Bar Crusher’s 585HT sets the standard of what to expect in a sub-6m hard top fishing boat…

COMPACT PROTECTION

Offering a full-height fixed hard top in a perfectly-balanced sub-6m package, the 585HT is ideal for bay, inshore and offshore fishing. The hard top configuration and fold-away rear bench seat combine to create a huge cockpit fishing area, while the Game Lock® coaming ensures a comfortable fish-fighting position. No other hard top boat in its class even comes close!

NEXT-GEN ADVANTAGE

Built on Bar Crusher’s innovative Gen2® hull, the 585HT combines key features including a wider negative chine running forward, optimised wider chine aft and the distinctive Delta Flare® – delivering greater hydrodynamic lift for efficient planing and excellent fuel economy, a higher bow attitude and better spray deflection for a drier ride, as well as increased stability at rest.

REALISE YOUR DREAM

The 585HT has everything the bigger hard top boats have, albeit in a compact and easy-to-tow package. Strong aluminium rod holders, livebait tank, in-floor fish storage tank, berley bucket, storage pockets, rocket launcher and baitboard are among the long list of fishing-related features. Option it up with an electric anchor winch, deck wash, FishMat tube matting… bring your dream boat to life.

HARD TOP COMFORT

Tough, premium-quality Bar Crusher plate aluminium boat construction, all-weather hard top protection, and factory-packaged on a custom-designed trailer with Bar Catch®, the 585HT is fitted as standard with a long list of functional features (items other manufacturers charge as extras)…

  • boat-builder-bar-crusher-waveslicer-hull-535-575-615

    Waveslicer®

  • boat-builder-bar-crusher-RIGIDECK-update

    Rigideck®

  • boat-builder-bar-crusher-quickflow-water-ballast-system-gen2

    Quickflow®

  • Boat Builder Bar Crusher Hard Top Windscreen Hardtop

    Hard top

  • boat-builder-bar-crusher-rocket-launcher-hard-top-ROCKETLHT

    Rocket launcher

  • boat-builder-bar-crusher-opening-forward-hatch-HATCHTINTED

    Forward hatch

  • boat-builder-bar-crusher-deck-grip

    Deck grip

  • boat-builder-bar-crusher-transom-step-through

    Step-through transom

EXCLUSIVE TECHNOLOGIES

SPECIFICATIONS

  • Length overall (mm) 5850
  • Beam (mm) 2150
  • Internal freeboard (mm) 730
  • Bottom sides (mm) 4
  • Top sides (mm) 3
  • Transom length (in) 25
  • Fuel capacity (L) 160
  • Fuel system SafeTank™
  • Tow weight (kg) – dry weight 1430
  • Minimum horsepower 90
  • Maximum horsepower 140
  • Overall length on trailer (mm) – hitch to prop 7200
  • Overall width on trailer (mm) 2150
  • Height on trailer (mm) 3050
  • Overall height with roof folded (mm) n/a
  • Maximum persons 5

Weights and measurements are approximate due to variations in packaging and fit-out. All weights and measurements must be confirmed with your dealer prior to ordering.

Disclaimer: Images and videos on this website are indicative of the style, fit-out and packaging of Bar Crusher boats, however Bar Crusher reserves the right to make changes to its products at any time, without notice, to continue to develop and improve the product range. Some images/videos show boats being used in extreme conditions. Such images/videos are for display purposes only. These images/videos were taken/filmed under controlled conditions using highly-competent skippers. Bar Crusher specifically advises users of Bar Crusher boats do not perform similar manoeuvres to those depicted in any such images/videos, and to drive boats cautiously at all times, inline with their level of experience and to the prevailing conditions.
