RECOMMENDED PRICE RANGE* – $68k to $79k(*To be used as price guide only. Price may vary depending on dealer packaging and freight.)

Bar Crusher’s 670XS is designed for the Top End barra fishing fraternity to handle the rough roads and long coastal runs to the most remote fishing locations.

The 670XS’s ultra-tough construction, rear centre console, re-positional seating, forward casting deck and massive underfloor storage deliver exactly what hardcore anglers demand.

Constructed from heavy duty, high-tensile 5mm (bottom sides) and 4mm (top sides) marine grade plate aluminium, the 670XS measures 6.70m LOA with a 2.35m beam. Its high-tech Waveslicer® non-pounding, deep-V hull delivers an ultra-smooth ride, the expertly-engineered Rigideck® sub-floor system ensures maximum hull strength and Bar Crusher’s exclusive Quickflow® water ballast technology ensures the boat is extremely stable at rest.

The innovative Quickflow® system incorporates a cavity running the full length of the keel that quickly fills with water when the boat is stationary, which lowers the chines into the water for greater stability, and drains in seconds as the boat moves forward to allow it to leap effortlessly onto the plane.

The optional Bar Flap™ system can be used to keep water out, to make the boat lighter in shallow-water applications; or to trap water in, to make the boat heavier when running in extreme rough-water situations.

Onboard, a large, fully-sealed and lockable hatch in the forward casting platform opens to reveal a cavernous storage area, which is perfect to stow camping gear out of the weather for extended trips to remote fishing destinations. Generous internal depth will ensure everyone feels secure when out on the water, while Bar Crusher’s exclusive Game Lock™ coaming creates a comfortable fish-fighting position. The spigots in the deck allow seats to be moved around the boat, or taken out altogether for maximum fishing space. The 670XS can be configured with three seats side by side behind the console and two seats in front of the helm position.

The functional centre console allows for installation of all gauges and controls, as well as offers convenient storage, while the fully-welded checkerplate deck is extremely easy to clean after solid days on the water.

Strong aluminium rod holders, livebait tank, in-floor fish storage tank, berley bucket, large-volume storage pockets, baitboard, and optional deck wash and anchor winch are among a long list of fishing-related features. Rod lockers can also be installed to specification.

Rated to carry a 175hp outboard, the 670XS’s superior performance capabilities, 170L fuel capacity (long-range tank also available), expansive fishing area, heavy-duty checkerplate deck and extensive options list make this boat ideal for serious anglers searching for a boat that can handle extended coastal journeys.

Every Bar Crusher boat is factory-packaged on a custom-designed trailer, which ensures towing, launching and retrieving is a breeze. Self-centering and aligning perfectly every time, Bar Crusher’s innovative Bar Catch™ system also allows for single-handed launch and retrieve.

*This hull is also available in SC (Side Console) configuration.

Features + -

Specifications + -

Hull length (mm)6700
Beam (mm)2350
Internal freeboard (mm)800
Bottom sides (mm)5
Top sides (mm)4
Transom length (in)25
Fuel capacity (L)170
Tow weight (kg) – dry weight1750
Minimum horsepower150
Maximum horsepower175
Overall length on trailer (mm) – hitch to prop8000
Overall width on trailer (mm)2350
Height on trailer (mm)2400
Overall height with roof folded (mm)n/a
